BARCODE SCANNER HONEYWELL MS 5145 ( RS232 ) SERIAL

Termination 10 pin modular RJ45

Cable Standard 1.5 m (5) straight; optional 2.7 m (9) coiled

ELECTRICAL

Input Voltage 5 VDC +

0.25 V

Power 675 mW

Operating Current 135 mA @ 5 VDC

DC Transformers Class 2; 5.2 VDC @ 200 mA; or Class 2, 5.2 VDC @ 650 mA

Laser Class IEC 60825-1:1993+A1:1997+A2:2001 Class 1

EMC FCC, ICES-003 & EN55022 Class B

ENVIRONMENTAL

Operating Temperature 0C to 40C (32F to 104F)

Storage Temperature -40C to 60C (-40F to 140F)

Humidity 5% to 95% relative humidity, non-condensing

Shock Designed to withstand 1.5 m (5) drops

Light Levels Up to 4842 Lux (450 footcandles)
